INTSUPERMAI 15C Refrigerating Dryer Air Compressor Refrigerated Freeze Dryer Air Compressor Drying and Dewatering Equipment Refrigeration Dryer 220V 35cfm Flow

Product parameter: Flow capacity：70 cfm Refrigerant Type：R134A Voltage：220V Power：800W Interface pipe diameter: ZG1.0 Air capacity: 2.5m³/min Work pressure: ≤1.0Mpa Inlet temperature: ≤80℃ Dew point temperature: 2-10℃ Working principle: The humid and high temperature compressed air flows into the front cooler after the heat exchange into the heat exchanger and the cold air discharged from the evaporator, so that the temperature of the compressed air into the evaporator is reduced. The air of the heat transfer into the evaporator through the evaporator heat transfer function and refrigerant heat exchange, the heat in the compressed air is taken away by the refrigerant, compressed air rapid cooling, the wet air moisture reaches saturation temperature rapid condensation, condensed water after condensation, after the unique air water separator high speed rotation, water due to the action of the centrifugal force and air separation, after separation of water from the automatic drainage valve. The lowest air pressure dew point after cooling can be up to 2℃ after cooling. After cooling the cold air flows through the air heat exchange and inlet of hot humid hot air heat exchange, the heat exchange of cold air for absorb the heat, the inlet air and the compressed air through the freezing system of secondary condenser and high temperature refrigerant heat exchange again make the outlet temperature is fully heated, to ensure that the outlet air pipeline is not exposed. At the same time, it makes full use of the outlet air cooling source to ensure the condensation effect of the freezing system and ensure the quality of the outlet air of the machine. Item Number: 1* 15C Refrigerating Dryer Air Compressor Refrigerated Freeze Dryer (239848)

• 【Working Principle】The humid and high temperature compressed air flows into the front cooler after the heat exchange into the heat exchanger and the cold air discharged from the evaporator, so that the temperature of the compressed air into the evaporator is reduced.
• 【Parameter】Flow capacity：70 cfm, Refrigerant Type：R134A, Voltage：220V, Power：800W, Interface pipe diameter: ZG1.0, Air capacity: 2.5m³/min, Work pressure: ≤1.0Mpa, Inlet temperature: ≤80℃, Dew point temperature: 2-10℃
• 【Adjustable】The drain time can be adjusted. If it needs to be adjusted longer, the SEC key on the left can be adjusted to 2 seconds, and the MIN key on the right can be adjusted to 5 minutes (0-10 middle).
• 【Easy To Install】Easy installation with the compact design is ready to use with a small footprint,matches the compressor's displacement, saving energyeasy maintenance and improved reliability.
• 【Note】Precision machine, as far as possible installed indoors, if outdoors, need to do rain, high temperature and other special protection. No rain, no corrosive gas; Low dust and relativeFlow capacity：70 cfm
